Yukon Photon XT Digital Nightvision Riflescope 6.5 x 50S.
High magnification.
Day and night use.
Large caliber shockproof.
Selectable integrated electronic reticles.
Mounting with standard 30 mm rings.
Safe eye relief.
Built-in IR illuminator.
Effective for the use with invisible IR illuminators.
Compact and lightweight.
Easy operation.
Day & night use
The Photon XT night vision riflescopes can be activated and used in the daylight without the fear of being damaged immediately or in the long run.
Selectable reticles
A reticle is electronically displayed on the screen and is permanently located in the plane of target image. The Photon XT’s internal memory contains 6 reticles of various shapes and applications in 3 colors.
Eyesafe eye relief
The Photon XT riflescopes feature a 60 mm eye relief - one of the best parameters in its class. The greater is the eye relief the less traumatic is the use of the scope, especially on hunting weapons with considerable recoil.
High shock resistance
The Photon XT riflescopes feature high shock resistance and can be used with rifled hunting weapon for such cartridges as 9.3?64, .30-06, .300, .375. etc, and with smooth-bore and airsoft weapon.
Easy mounting on a rifle
The middle part of the Photon XT body is a 30 mm tube, standard for daylight optical sights, which enables the Photon to be mounted on various types of hunting weapons using proven solutions.
Effective use with 'invisible' IR illuminators
As opposed to tube-based devices, digital NV equipment feature advanced efficiency when used with IR Illuminators working in long wave range (more than 900 nm) and invisible by the naked eye.
Easy to operate
Photon XT riflescope is easy to operate - majority of operations (device activation, menu settings and navigation) are performed with one encoder-wheel.
Compact and lightweight
Being an electronic and optic night vision riflescope Photon XT has the weight and size of an ordinary day riflescope.
Specification:
Spectral sensitivity of device at a wavelength of 780 nm, mW, not more than: 6.5x10^-5
Spectral sensitivity of device at a wavelength of 915 nm, mW, not more than: 4x10^-4
Sensor Type: CMOS
Camera resolution, pixels: 656 x 492
Display type: LCD
Display Resolution, pix.: 640x480
Magnification, x: 6.5
Lens diameter, mm: 50
Field of View, degree: 4.3
Eye Relief, mm: 60
Exit Pupil, mm: 5
Diopter adjustment, dptr.: ±4
Resolution, lines per mm: 38
Minimum focusing distance, m: 10
Range of recognition, m: 150
Emitter: LED
IR Wavelenght, nm: 810
Power of IR Illuminator, mW: 14.7...18.4
IR Illuminator’s beam divergence angle, degree: 5
Windage & Elevation, 1 click, mm / 100m: 17/ 17
Max. windage/elevation adjustment range, clicks: 1020/ 1020
Mounting brackets on weapon: 30 mm rings
Shock Resistance (when used with rifled gun), E0, joules: 6000
Power supply, V: 2.0 - 3.3
Weight (without/with battery), kg: 0.62/ 0.67
Battery Type: 2 x LR6
Operating Temperature, °C: - 15 ... + 50
Level of Protection (acc. to IEC 60529) IPX4
Video Out : yes/ no *
Type of Accessory Mounting Rails: Weaver
Dimensions, mm: 398x75x80
